OPRANIC P7 Glass Infrared Panel Heater 450W – 900W in White or Black

Overview

The OPRANIC P7 Series glass heaters are premium infrared heaters designed with highly efficient dark infrared heating technology. Available in outputs up to 900 watts, these infrared heaters feature innovative twin heat conductor technology and 98% energy efficiency. OPRANIC P7 Series infrared heaters have a sophisticated tempered glass construction with an elegant appearance. Despite their slim profile with a depth of only 2,5 cm, they offer robust heating performance. The OPRANIC P7 Series is IP44 rated, making it resistant to splash water and moisture, and suitable for use in bathrooms. With integrated overheating protection and built-in safety switches to prevent the panels from reaching dangerous temperatures, these infrared heaters are both safe and reliable. They are smart home compatible and come with advanced insulation and robust construction. Each infrared heater is backed by a 5-year warranty, guaranteeing reliable and long-lasting performance.

Technical Specifications

• Material: Tempered Safety Glass Construction
• Power Supply: 230V / 50Hz with a 1,9 m power cord
• Dimensions:
  • 450 Watts: 60 x 60 x 2,5 cm
  • 700 Watts: 60 x 90 x 2,5 cm
  • 900 Watts: 60 x 120 x 2,5 cm
• Weight:
  • 450 Watts: 10,3 kg
  • 700 Watts: 15,4 kg
  • 900 Watts: 19 kg
• Protection Class: I
• Heating Coverage: Exclusively for closed interior spaces
  • 450 watts: up to approximately 12 m²
  • 700 watts: up to approximately 16 m²
  • 900 watts: up to approximately 20 m²

The above heating coverage estimates are based on measurements and tests conducted in well-insulated rooms. Actual heating area coverage may vary due to factors such as ceiling height, room size, insulation quality, building structure, and the number of external walls.

Mounting

• Only for wall mounting
• Mounting bracket included in delivery
• Quick Installation

Heating Technology

Heating Filament: Twin heat conductor technology with a serpentine layout for uniform heat distribution and no additional magnetic fields. The heating filament extends up to the edges of the heater, ensuring a uniform surface temperature and efficient heat radiation without hot spots.

Rear Insulation: High-quality aluminum reflector with a 2,5 cm mineral thermal insulation layer for targeted heat reflection forward into the room, minimizing energy loss. This design is highly efficient and safe.

Radiation Efficiency

Our infrared heaters are designed for optimal energy conversion, ensuring that more electrical energy is directly converted into warmth. They exceed industry standards, providing efficient heating for both small and large spaces. OPRANIC infrared heaters deliver consistent heat distribution with minimal energy loss, resulting in significant savings on heating costs.

Energy Optimization with Thermostat

For efficient energy optimization, we recommend using infrared heaters with a thermostat. The thermostat is not included in the product package. The selection of a suitable thermostat depends on the intended application. OPRANIC P7 Series Infrared Heaters have an open interface, making them compatible with any thermostat system. They are also designed for integration into smart home environments and are compatible with thermostats from other manufacturers.

Safety Features and Safety Use

• Overheating Protection: Integrated safety switch prevents dangerous temperatures.
• IP44 Rating: Protects against splashing water, suitable for bathroom use.
• Safety Distances: Maintain a safety distance of 30 cm in front and 10 cm on all sides, including upwards and downwards, from flammable objects.

Applications

Ideal for living rooms, offices, bathrooms, bedrooms, kitchens, children's rooms, laundry rooms, basements and attics, hobby rooms, garden houses, sunrooms, holiday homes, small apartments, greenhouse, etc.

Mounting Instructions

Suited for wall mounting, the brackets included in the package allow the heater to be installed horizontally or vertically, providing flexibility for your space. The package includes a patented mounting bracket that ensures secure attachment. To install, fasten the bracket to the ceiling or wall with the supplied screws and dowels. Then, slide the heater into place and turn the safety bracket for a secure and simple installation. For optimal heating performance, we recommend a maximum distance of 3 to 4 meters from the desired heating area.

Delivery Contents

• 1 x OPRANIC P7 Glass Infrared Heater
• 1 x Patented Mounting Bracket
• 1 x Installation Kit (dowels & screws)
• 1 x User Manual
• 1 x Integrated Power Cord

Technical Data

• Colour: White
• Performance: 450W, 700W, and 900W models
• Maximum Efficiency: Approximately 98% of electrical energy converted to thermal output
• Heatable Area: Up to 20 square meters depending on the model

The OPRANIC P7 Series combines advanced infrared technology with sleek design for an efficient and safe heating solution, suitable for various indoor applications.

Regulation (EU) 2015/1188

Please refer to the EU Ecodesign Regulation 2015/1188. To operate the heating in accordance with EU Regulation No. 2015/118, please use an additional electronic thermostat system that has "window open" detection and weekday programming. This product is only suitable for well-insulated rooms or for occasional use (EU Regulation 2015/1188 Article 3, Annex II b) II (2). The room temperature controller is not part of the product. Since the interfaces are open, you can either use your own thermostat system or, for example, our OT50 thermostat system. The OPRANIC P7 Series has a mechanically integrated surface thermostat.
